Suitable for residential and light commercial applications such as House, Countryside, Island, Pasture, Telecom, Farm.
Dual MPPT with up to 99.9% efficiency
Up to 22A PV input current perfect for high-power modules
Industrial design with a modern aesthetic look
Easy to install and simple to use
Solar Charger Controller up to 200A charging current
Support for Li-ion battery BMS communication
Outputs high-quality pure sine wave AC power
8-10kW load power to meet the needs of most households
360 degrees of security from hardware to software
EU and North American safety approvals
Exclusive Li-ion battery BMS dual activation
Time-slot function to save cost with peak-valley tariff
| Model | LS-SPI8KS | LS-SPI10KS | CAN BE SET |
| INVERTER | |||
| Rated Output Power | 8000W | 10000W | |
| Max.Peak Power | 16000W | 20000W | |
| Rated Output Voltage | 230Vac（single-phase L1/N/PE） | Y | |
| Load Capacity of Motors | 5HP | 6HP | |
| Rated AC Frequency | 50/60Hz | Y | |
| Waveform | Pure Sine Wave | ||
| Switch Time | 10ms (typical) | ||
| Parallel Capacity | / | ||
| BATTERY | |||
| Battery Type | Li-ion/Lead-Acid /User Defined | Y | |
| Rated Battery Voltage | 48Vdc | ||
| Voltage Range | 40～60Vdc | Y | |
| Max.MPPT Charging Current | 200A | Y | |
| Max.Mains/Generator Charging | 100A | 120A | Y |
| Max.Hybrid Charging Current | 180A | 200A | Y |
| PV INPUT | |||
| Num.of MPPT Trackers | 2 | ||
| Max.PV Array Power | 11000W | ||
| Max.Input Current | 22/22A | ||
| Max.Voltage of Open Circuit | 500Vdc | ||
| MPPT Voltage Range | 125~425Vdc | ||
| UTILITY/ GENERATOR INPUT | |||
| Input Voltage Range | 90～275Vac | ||
| Frequency Range | 50/60Hz | ||
| Bypass Overload Current | 63A | ||
| EFFICIENCY | |||
| MPPT Tracking Efficiency | 99.9% | ||
| Max. Battery Inverter Efficiency | 92% | ||
| GENERAL | |||
| Dimensions | 620*435*130mm | ||
| Weight | 27kg | ||
| Protection Degree | IP20,Indoor Only | ||
| Operating Temperature Range | -10~55℃,>45℃ derated | ||
| Humidity | -25℃~60℃ | ||
| Cooling Method | Internal Fan | ||
| Warranty | 1Years | ||
| COMMUNICATION | |||
| Embedded Interfaces | RS485/CAN/USB/ Dry contact | Y | |
| External Modules(Optional) | Wi-Fi/GPRS | Y | |
| CERITIFACATION | |||
| Safety | IEC62109-1,IEC62109-2,UL1741 | ||
| RoHs | Yes | ||
| EMC | EN61000-6-1,EN61000-6-3,FCC 15 class B | ||
